Ballast Output Wattage | 230 |
Ballast Dimensions(mm) | 135X50X30 |
Input Voltage | DC380V—DC400V |
Input Current | 0.63A |
Output Voltage | AC75V--AC85V |
Output Current | 3A--2.7A |
Output no-load Voltage | 200V (trigger) |
Output no-load Voltage | 50V( without bulb) |
Frequency(Hz) | 100 |
Output Power Factor | 0.985 |
Adaptive Temperature | -20℃—+40℃ |
